Predicting Vertical Ground Reaction Force Characteristics during Running with Machine Learning

Provisionally accepted
Sieglinde Bogaert Sieglinde Bogaert 1*Jesse Davis Jesse Davis 2,3Benedicte Vanwanseele Benedicte Vanwanseele 1
  • 1 Human Movement Biomechanics Research Group, Department of Movements Sciences, KU Leuven, Leuven, Belgium
  • 2 Department of Computer Science, Faculty of Sciences, KU Leuven, Leuven, Belgium
  • 3 Institute for Artificial Intelligence, KU Leuven, Leuven, Belgium

The final, formatted version of the article will be published soon.

    Running poses a high risk of developing running-related injuries (RRIs). The majority of RRIs are the result of an imbalance between cumulative musculoskeletal load and load capacity. A general estimate of whole-body biomechanical load can be inferred from ground reaction forces (GRFs).Unfortunately, GRFs typically can only be measured in a controlled environment, which hinders its wider applicability. The advent of portable sensors has enabled training machine-learned models that are able to monitor GRF characteristics associated with RRIs in a broader range of contexts.Our study presents and evaluates a machine-learning method to predict the contact time, active peak, impact peak, and impulse of the vertical GRF during running from three-dimensional sacral acceleration. The developed models for predicting active peak, impact peak, impulse, and contact time demonstrated a root-mean-squared error of 0.080 body weight (BW), 0.198 BW, 0.0075 BW • seconds, and 0.0101 seconds, respectively. Our proposed method outperformed a mean-prediction baseline and two established methods from the literature. The results indicate the potential utility of this approach as a valuable tool for monitoring selected factors related to running-related injuries.

    Keywords: Running, machine learning, Vertical ground reaction force, Inertial measurement unit, Contact time, Active peak, Impact peak, impulse
