Frederik Buchholz ^1* Martin Meffert ¹ Pierre-Louis Bazin ² Robert Trampel ³ Robert Turner ³ Peter Schoenknecht ^1*

• ¹ University Hospital Leipzig, Leipzig, Germany
• ² Full brain picture analytics, Leiden, Netherlands
• ³ Max Planck Institute for Human Cognitive and Brain Sciences, Leipzig, Lower Saxony, Germany

The subgenual Anterior Cingulate Cortex (sgACC), as a part of the Anterior Cingulate Cortex and the limbic system plays a crucial role in mood regulation. Previous structural brain imaging studies of the sgACC have revealed alterations of Gray Matter (GM) volumes in patients with Major Depressive Disorder (MDD) and Bipolar Disorder (BD), suggesting potential biomarker traits for affective disorders. In this study we investigated the gray matter volume of the sgACC in 3 different patient groups: 40 MDD patients, of which 20 were medicated (MDDm) and 20 were unmedicated (MDDu), and 21 medicated BD patients, and compared them with 23 healthy volunteers. We examined GM volume alteration using high-resolution 7T Magnetic Resonance Imaging (MRI) which produced quantitative maps of the spin-lattice relaxation time (T1). T1 maps provide high contrast between gray and white matter, and at 7 Tesla voxels with submillimeter resolution can be acquired in a reasonable scan time. We developed a semi-automatic segmentation protocol based on refined landmarks derived from previous volumetric studies using quantitative T1 maps as raw input data for automatic tissue segmentation of GM, WM and CSF (cerebrospinal fluid) tissue. The sgACC ROI was then traced manually by two independent raters (F.B., M.M.) following our semi-automatic segmentation protocol. Interrater reliability was calculated on a subset of 10 brain scans for each hemisphere, showing an Intra-Class Correlation coefficient (ICC) r = 0.96 for left sgACC and r = 0.84 for right sgACC respectively. In summary, we have developed a reproducible and reliable semi-automatic segmentation protocol to measure gray matter volume in the sgACC. Based on previous findings from meta-analyses on morphometric studies of the sgACC, we hypothesized that patients with MDD would have lower gray matter sgACC volumes compared to healthy subjects. Post-hoc analysis revealed smaller subgenual volumes for the left hemisphere in both the medicated (MDDm) and non-medicated (MDDu) group versus healthy controls (p = .001, p = .008) respectively. For the right hemisphere, the (MDDu) and BD group exhibited significantly lower subgenual volumes than healthy controls (p < .001, p = .004) respectively.
