Synthetic Fibrosis Distributions for Data Augmentation in Predicting Atrial Fibrillation Ablation Outcomes: an In-silico Study

Alexander Zolotarev ^* Kiane Johnson Yusuf Mohammad Omnia Alwazzan Greg Slabaugh Caroline Roney ^*

• Queen Mary University of London, London, United Kingdom

Introduction Cardiac fibrosis influences atrial fibrillation (AF) progression and ablation outcomes, with Late Gadolinium Enhancement (LGE) MRI providing a non-invasive tool to measure fibrosis distributions. While deep learning (DL) has shown promise in predicting ablation success, training such pipelines is limited by the availability of real patient data. Methods In this study, we generated synthetic fibrosis distributions using a Denoising Diffusion Probabilistic Model trained on a collection of 100 real LGE-MRI distributions. We incorporated them into 1000 bi-atrial meshes derived from a statistical shape model and simulated AF episodes on them before and after various ablation strategies to expand training dataset for DL-based outcome prediction. Our approach aims to improve predictive performance of DL pipeline by enhancing dataset diversity and better capturing patient variability. Results We showed that the fibrosis distributions generated by the diffusion model closely resemble real LGE-MRI distributions, based on metrics such as mean intensities (1.1 ± 0.2 versus 1.1 ± 0.3) and average Shannon entropy (0.77 ± 0.06 and 0.81 ± 0.03). AF biophysical simulations can be effectively conducted on bi-atrial meshes incorporating these synthetic distributions. Training the deep learning pipeline on these simulations produces performance metrics comparable to those achieved with real LGE-MRI distributions (ROC-AUC = 0.952 vs. 0.943).We have shown the ability of synthetic fibrosis distributions to be a data augmentation tool for deep learning classification of outcomes of various ablation strategies, which may enable rapid and precise assessment of Atrial Fibrillation treatment strategies.
