REVIEW article
Front. Bioeng. Biotechnol.
Sec. Biomaterials
Volume 13 - 2025 | doi: 10.3389/fbioe.2025.1549439
Advanced Surface Modification Techniques for Titanium Implants: A Review of Osteogenic and Antibacterial Strategies
Provisionally accepted- 1 Department of Orthopedic Surgery, The First Affiliated Hospital of Shandong First Medical University & Shandong Provincial Qianfoshan Hospital, Jinan, Shandong Province, China
- 2 The Second Affiliated Hospital of Xi’an Jiaotong University, Department of Bone and Joint Surgery, Xi’an, China
Titanium (Ti) implants are widely used in orthopedic and dental applications due to their excellent mechanical strength, corrosion resistance, and biocompatibility. However, their limited osteointegration and susceptibility to bacterial infections remain major clinical challenges. Recent advancements in surface modification techniques have significantly improved the osteogenic and antibacterial properties of Ti implants. This review summarizes key strategies, including ion doping, hydroxyapatite (HAp) coatings, nanostructured surfaces, and graphene-based modifications. Zinc (Zn)-doped coatings increase osteoblast proliferation by 25%, enhance cell adhesion by 40%, and inhibit Staphylococcus aureus by 24%. Magnesium (Mg)-doped Ti surfaces enhance osteoblast differentiation, with 38% increased alkaline phosphatase (ALP) activity and a 4.5-fold increase in cell proliferation. Copper (Cu)-doped coatings achieve 99.45% antibacterial efficacy against S. aureus and 98.65% against Escherichia coli (E. coli). Zn-substituted HAp promotes mineralized nodule formation by 4.5-fold and exhibits 16.25% bacterial inhibition against E. coli. Graphene-based coatings stimulate bone marrow stem cells (BMSCs) and provide light-responsive surface potentials for enhanced osteogenesis. Despite these advancements, challenges remain in optimizing ion release kinetics and long-term stability. Future research should focus on multi-functional coatings that integrate osteogenic, antibacterial, and immunomodulatory properties to enhance clinical performance and patient outcomes. Highlight: (1) Innovative Surface Modification Strategies: Integrating metal doping, HAp coatings, and graphene modifications to significantly enhance osseointegration, antibacterial properties, and biocompatibility.(2) Synergistic Effects of Multifunctional Coatings: Exploring interactions among metal ions, HAp, and graphene composite coatings to optimize osteogenesis, antibacterial efficacy, and mechanical properties.(3) Addressing Clinical Translation Challenges: Focusing on ion release control, long-term stability, and large-scale manufacturing to advance personalized implants and clinical applications.
Keywords: Titanium, Biomechanical, Surface modification, Osteointegration, Antibacterial, Macrophage polarization
Received: 02 Jan 2025; Accepted: 24 Feb 2025.
