Awni Alshurafa
Mohammad Elhissi2
Mohamed A. Yassin- 1Department of Hematology, Hamad Medical Corporation, Doha, Qatar
- 2Clinical Imaging Department, Hamad Medical Corporation, Doha, Qatar
Avascular necrosis (AVN) or joint osteonecrosis is a debilitating complication of sickle cell disease, increasing the disease burden on both patients and healthcare systems. AVN can be radiologically categorized into early and late stages depending on the extent of the disease. Management of AVN is challenging and controversial. Generally, it includes conservative measures for early disease to preserve the joint for as long as possible and surgical management for more advanced diseases. Hyperbaric oxygen (HBO) therapy can be used as primary or adjunctive therapy for different medical disorders. Currently, the main rule of HBO in AVN is an adjunctive therapy to control symptoms and improve the quality of life of a patient; however, the concept of using HBO as a primary treatment choice for AVN in patients with sickle cell disease is not well evaluated yet. In this case study, we reported a 15-year-old boy with sickle cell disease who was suffering from stage II AVN in bilateral femoral and right shoulder joints. A total of 57 sessions of HBO resulted in the complete resolution of AVN in post-treatment MRI.
Introduction
Sickle cell disease is an inherited disorder of the globulin chains and the most common genetic disorder in the United States (1). Patients with sickle cell disease (SCD) are at a high risk of a variety of serious organ system complications. Recurrent vaso-occlusive crisis, chronic hemolysis, hypercoagulability, and fat emboli are the main mechanisms of end-organ injury in SCD (2–5). Avascular necrosis (AVN) is a well-reported complication that affects around 10% of patients with SCD (6). It can result in severe pain and loss of joint function affecting the patient’s quality of life. AVN can be radiologically categorized into early and late stages depending on the extent of the disease (7).
The management of AVN is challenging and controversial. Generally, it includes conservative measures for early disease to preserve the joint for as long as possible, while surgical options are usually kept for more advanced diseases (8). Conservative measures may include physical therapy, offloading as tolerated, and pain management. Low-molecular-weight heparin may decrease the progression rate of idiopathic osteonecrosis from the pre-collapse to the collapsed stage (9, 10).
Hyperbaric oxygen (HBO) is a treatment modality in which individuals breathe 100 % of oxygen which may improve AVN by increasing the oxygen supply to joints. Currently, its main role in AVN is to control joint pain, improve the range of motion, and delay joint loss (11, 12). Some studies reported radiographic improvement in AVN stages I and II with HBO (13). However, the complete resolution of stage II AVN by HBO has not been reported before.
In this case study, we reported a 15-year-old boy with SCD, who was suffering from stage II avascular necrosis in both hips and right shoulder joints. A total of Fifty-seven sessions of HBO resulted in the complete resolution of AVN in post-treatment MRI.
Case report
We report a 15-year-old boy who was suffering from a known case of non-transfusion-dependent SCD (hemoglobin SS) and was on hydroxyurea of 1,000 mg daily. His disease course was complicated by a chronic aching pain and a limited range of motion in both hip and right shoulder joints. An MRI showed geographic subarticular high-signal intensities in STIR sequences with no femoral or humeral head collapse of both hip joints and right shoulder joint in keeping with a stage II AVN of both femurs and right shoulder (Figures 1A, 2A, 3A). Apart from SCD, there were no other risk factors for AVN.
Figure 1. (A) Coronal STIR (short T1 inversion recovery) of the right hip before treatment with HBO showing geographic subarticular area of high-signal intensity (arrow) with no collapse of the head of the femur (stage II). (B) Coronal STIR (short T1 inversion recovery) of the right hip after treatment showing complete resolution of the previously seen subarticular high-signal intensity suggests complete radiological resolution of avascular necrosis.
Figure 2. (A) Coronal STIR (short T1 inversion recovery) of the left hip before treatment with HBO showing geographic subarticular area of high-signal intensity (arrows) with no collapse of the head of the femur (stage II). (B) Coronal STIR (short T1 inversion recovery) of the left hip after treatment showing complete resolution of the previously seen subarticular high-signal intensity suggests complete radiological resolution of avascular necrosis.
Figure 3. (A) Axial STIR (short T1 inversion recovery) of the right shoulder before treatment with HBO showing geographic subarticular area of high-signal intensity (arrow) with no collapse of the head of the femur (stage II). (B) Axial STIR (short T1 inversion recovery) of the right shoulder after treatment showing complete resolution of the previously seen subarticular high-signal intensity suggests complete radiological resolution of avascular necrosis.
Conservative measures were tried with pain management, offloading, and physiotherapy without significant clinical improvement. Thus, the patient and family were given counseling about HBO to control the joint pain and reduce analgesic use and they agreed to the treatment.
A total of 57 sessions of HBO therapy was given; it was five sessions per week that lasted for 2 h with a pressure of 2.5 pounds per square inch. The treatment was well-tolerated, and the course was uneventful of any side effects. The number of sessions was guided by clinical improvement.
The patient showed significant clinical improvement in the form of pain resolution and range of motion improvement. Post-treatment MRI showed total resolution of the previously noted geographic subarticular high-signal intensities of both hip joints and right shoulder joint denoting complete resolution (Figures 1B, 2B, 3B) of the AVN in affected joints.
Discussion
Avascular necrosis or osteonecrosis is a debilitating complication of SCD, increasing the disease burden on both patients and healthcare systems. Radiologically, AVN can be divided into pre-collapse and post-collapse of the subchondral surface. Although the management of AVN in patients with SCD is controversial, initially, conservative measures are usually tried because it is less invasive and may be effective for some individuals. Patients and their families are increasingly involved in making treatment decisions (14, 15).
Hyperbaric oxygen therapy is a treatment modality that can be used as primary or adjunctive therapy for different medical disorders. Although the therapy is not approved worldwide, the main rule of HBO in AVN is an adjunctive treatment to control symptoms and to improve the quality of life of a patient; however, the concept of using HBO as a primary treatment choice for AVN in patients with SCD is not well established yet (13, 16).
In a recently published systematic review and meta-analysis assessing the use of HBO in femoral head AVN, regardless of the underlying etiology, Paderno et al. showed that patients with femoral head AVN managed with HBO can achieve a significant clinical improvement in the form of pain reduction and improvement in the range of hip motion; however, the radiological outcome was not described (13). In a double-blind, randomized, controlled, prospective study evaluating HBO therapy in 20 patients with femoral head necrosis, Camporesi et al. showed that besides clinical improvement, there was a continuous radiological improvement in most studied patients at 7 years of follow-up; however, most of the radiographic changes were seen between the baseline MRI and the 12-month post-treatment follow-up images (17). In an SCD-related AVN, Shier et al. reported three cases of pre-collapse femoral head AVN. Of the three cases, two cases showed significant clinical and radiological improvement with HBO (11).
The exact mechanism of the therapeutic effects of HBO in AVN is not yet fully understood. HBO acts by giving oxygen at high atmospheres of pressure, resulting in an increased level of dissolved oxygen in the plasma, and in turn, more oxygen reaches the tissues (18). At the molecular level, the main players in bone turnover are specific cytokines osteoprotegerin (OPG), receptor activator of NF-kB (RANK), and its ligand (RANKL). Any change in the OPG/RANKL/RANK interaction will lead to a shift either to bone formation or resorption. Previous studies showed that there were interactions between inflammatory factors such as interleukin-1 beta (IL-1b), interleukin-6 (IL-6), tumor necrosis factor-alpha (TNF-a), and the OPG/RANK/RANKL. Bosco et al. showed a significant decrease in TNF-a and IL-6 plasma levels with HBO therapy over time. This decrease in inflammatory markers corresponded to reductions in joint pain and bone marrow edema on imaging (19–21).
Hyperbaric oxygen therapy is generally well-tolerated, and most side effects are mild and reversible. Pressure is usually maintained between 2.5 and 3.0 atm, while session number and duration are usually decided according to the indication; one or two sessions may be needed in acute settings, while more extended treatment is usually required for chronic medical conditions (22). The role of novel therapies in the sickle cell-related AVN is still not clear (23–25). In our case, the patient was complaining of chronic aching pain in three joints and requiring frequent analgesic use. HBO was started to control pain and delay joint loss. However, clinical and radiological follow-up showed a complete resolution of previously reported stage II AVN.
In conclusion, HBO therapy may be used as a primary treatment modality in an SCD-related AVN in both controlling symptoms and ameliorating radiological findings; however, further studies are needed to confirm these findings.
Data availability statement
The original contributions presented in this study are included in the article/supplementary material, further inquiries can be directed to the corresponding author.
Ethics statement
Written informed consent was obtained from the individual for the publication of any potentially identifiable images or data included in this article.
Author contributions
All authors listed have made a substantial, direct, and intellectual contribution to the work, and approved it for publication.
Conflict of interest
The authors declare that the research was conducted in the absence of any commercial or financial relationships that could be construed as a potential conflict of interest.
Publisher’s note
All claims expressed in this article are solely those of the authors and do not necessarily represent those of their affiliated organizations, or those of the publisher, the editors and the reviewers. Any product that may be evaluated in this article, or claim that may be made by its manufacturer, is not guaranteed or endorsed by the publisher.
References
1. Khamees I, Ata F, Choudry H, Soliman AT, De Sanctis V, Yassin MA. Manifestations of HbSE sickle cell disease: a systematic review. J Trans Med. (2021) 19:262. doi: 10.1186/s12967-021-02931-1
2. Yassin M, Soliman A, De Sanctis V, Nashwan A, Abusamaan S, Moustafa A, et al. Liver iron content (LIC) in adults with sickle cell disease (SCD): correlation with serum ferritin and liver enzymes concentrations in trasfusion dependent (TD-SCD) and non-transfusion dependent (NT-SCD) patients. Mediterr J Hematol Infect Dis. (2017) 9:e2017037. doi: 10.4084/MJHID.2017.037
3. Wali Y, Kini V, Yassin MA. Distribution of sickle cell disease and assessment of risk factors based on transcranial doppler values in the Gulf region. Hematol Amst Neth. (2020) 25:55–62. doi: 10.1080/16078454.2020.1714113
4. Soliman AT, Yasin M, El-Awwa A, Abdelrahman MO, De Sanctis V. Does blood transfusion affect pituitary gonadal axis and sperm parameters in young males with sickle cell disease? Indian J Endocrinol Metab. (2013) 17:962–8. doi: 10.4103/2230-8210.122599
5. Yassin MA, Soliman AT, De Sanctis V, Abdula MAJ, Riaz LM, Ghori FF, et al. Statural growth and prevalence of endocrinopathies in relation to liver iron content (LIC) in adult patients with beta thalassemia major (BTM) and sickle cell disease (SCD). Acta Bio Med Atenei Parm. (2018) 89:33–40. doi: 10.23750/abm.v89i2-S.7085
6. Vanderhave KL, Perkins CA, Scannell B, Brighton BK. Orthopaedic manifestations of sickle cell disease. J Am Acad Orthop Surg. (2018) 26:94–101. doi: 10.5435/JAAOS-D-16-00255
7. Lee G-C, Khoury V, Steinberg D, Kim W, Dalinka M, Steinberg M. How do radiologists evaluate osteonecrosis? Skeletal Radiol. (2014) 43:607–14. doi: 10.1007/s00256-013-1803-4
8. Yawn BP, Buchanan GR, Afenyi-Annan AN, Ballas SK, Hassell KL, James AH, et al. Management of sickle cell disease: summary of the 2014 evidence-based report by expert panel members. JAMA. (2014) 312:1033–48. doi: 10.1001/jama.2014.10517
9. Chotanaphuti T, Thongprasert S, Laoruengthana A. Low molecular weight heparin prevents the progression of precollapse osteonecrosis of the hip. J Med Assoc Thail Chotmaihet Thangphaet. (2013) 96: 326–1330.
10. Molinari AC, Banov L, Bertamino M, Barabino P, Lassandro G, Giordano P. A practical approach to the use of low molecular weight heparins in VTE treatment and prophylaxis in children and newborns. Pediatr Hematol Oncol. (2015) 32:1–10. doi: 10.3109/08880018.2014.960119
11. Shier A, Abdelrazek M, Soliman A, De Sanctis V, Elsayed A, Abdulla M, et al. Short-term outcome and mri changes in three adult patients with sickle cell disease and aseptic osteonecrosis after treatment with hyperbaric oxygen therapy: a preliminary report. Case Rep Oncol. (2020) 13:365–72. doi: 10.1159/000506330
12. Salameh M, Moghamis IS, Kokash O, Ahmed GO. Hyperbaric oxygen therapy for the treatment of steinberg I and II avascular necrosis of the femoral head: a report of fifteen cases and literature review. Int Orthop. (2021) 45:2519–23. doi: 10.1007/s00264-021-05120-3
13. Paderno E, Zanon V, Vezzani G, Giacon TA, Bernasek TL, Camporesi EM, et al. Evidence-supported HBO therapy in femoral head necrosis: a systematic review and meta-analysis. Int J Environ Res Public Health. (2021) 18:2888. doi: 10.3390/ijerph18062888
14. Aguilar C, Vichinsky E, Neumayr L. Bone and joint disease in sickle cell disease. Hematol Oncol Clin North Am. (2005) 19:929–41. doi: 10.1016/j.hoc.2005.07.001
15. Giordano P, Urbano F, Lassandro G, Faienza MF. Mechanisms of bone impairment in sickle bone disease. Int J Environ Res Public Health. (2021) 18:1832. doi: 10.3390/ijerph18041832
16. Gill AL, Bell CNA. Hyperbaric oxygen: its uses, mechanisms of action and outcomes. QJM Mon J Assoc Phys. (2004) 97:385–95. doi: 10.1093/qjmed/hch074
17. Camporesi EM, Vezzani G, Bosco G, Mangar D, Bernasek TL. Hyperbaric oxygen therapy in femoral head necrosis. J Arthr. (2010) 25:118–23. doi: 10.1016/j.arth.2010.05.005
18. Mathieu D, Marroni A, Kot J. Tenth european consensus conference on hyperbaric medicine: recommendations for accepted and non-accepted clinical indications and practice of hyperbaric oxygen treatment. Diving Hyperb Med. (2017) 47:24–32. doi: 10.28920/dhm47.1.24-32
19. Bosco G, Vezzani G, Mrakic Sposta S, Rizzato A, Enten G, Abou-Samra A, et al. Hyperbaric oxygen therapy ameliorates osteonecrosis in patients by modulating inflammation and oxidative stress. J Enzyme Inhib Med Chem. (2018) 33:1501–5. doi: 10.1080/14756366.2018.1485149
20. Vezzani G, Quartesan S, Cancellara P, Camporesi E, Mangar D, Bernasek T, et al. Hyperbaric oxygen therapy modulates serum OPG/RANKL in femoral head necrosis patients. J Enzyme Inhib Med Chem. (2017) 32:707–11. doi: 10.1080/14756366.2017.1302440
21. Kurokouchi K, Kambe F, Yasukawa K, Izumi R, Ishiguro N, Iwata H, et al. TNF-alpha increases expression of IL-6 and ICAM-1 genes through activation of NF-kappaB in osteoblast-like ROS17/2.8 cells. J Bone Miner Res Off J Am Soc Bone Miner Res. (1998) 13:1290–9. doi: 10.1359/jbmr.1998.13.8.1290
22. Camporesi EM, Bosco G. Mechanisms of action of hyperbaric oxygen therapy. Undersea Hyperb Med J Undersea Hyperb Med Soc Inc. (2014) 41:247–52.
23. Alshurafa A, Yassin MA. Case report: safety and efficacy of voxelotor in a patient with sickle cell disease and stage IV chronic kidney disease. Front Med. (2022) 9:2022. doi: 10.3389/fmed.2022.931924
24. Elenga N, Loko G, Etienne-Julan M, Al-Okka R, Adel AM, Yassin MA. Real-world data on efficacy of L-glutamine in preventing sickle cell disease-related complications in pediatric and adult patients. Front Med. (2022) 9:931925. doi: 10.3389/fmed.2022.931925
