Dual H-Bridge Integrated Multiport DC Circuit Breaker for Bus Fault Interruption in HVDC Grids Supporting Large-Scale Renewable Energy Integration

Provisionally accepted
Hui Qin Hui Qin 1*Zhen Pan Zhen Pan 1*Yuxin Lu Yuxin Lu 2*Changyue zou Changyue zou 2*Xuebo Qiao Xuebo Qiao 2*Yunfeng Huang Yunfeng Huang 1
  • 1 Guangxi Power Grid Corporation, Nanning, China
  • 2 Electric Power Research Institute, CSG, Guangzhou, China

The final, formatted version of the article will be published soon.

    To address the technical challenge of rapid and reliable interruption of DC faults in offshore wind power DC collection and transmission systems, which are critical for large-scale renewable energy integration, this paper proposes an integrated multi-port DC circuit breaker (DCCB) with bus fault clearing capability based on a dual H-bridge configuration. By extending a pair of bridge arms in the H-bridge to connect to the DC bus and employing diodes in the load commutation switches (LCSs) to form the second H-bridge, the proposed DCCB not only achieves conventional line fault clearing but also has the ability to interrupt bus faults. A five-terminal offshore wind power DC transmission system simulation model was built in PSCAD/EMTDC to verify the performance of the DCCB under various operating conditions. The results demonstrate that the proposed multi-port DCCB can protect multiple DC lines effectively under different conditions.

    Keywords: offshore wind power, Multi-port, dc circuit breaker, H-bridge, DC fault

    Received: 20 Nov 2024; Accepted: 16 Dec 2024.
